Description
The RocketRAID 620 6 Gbps SATA RAID Host Adapter from HighPoint connects internal or external SATA devices. RAID levels 0, 1, 5, 10 and JBOD helps in optimizing storage performance and redundancy. The data ports deliver high performance while external disk enclosures with port multiplier enable higher storage capacities.
Additional information
| Weight | 0.45 lbs |
|---|---|
| Dimensions | 7.9 × 7 × 1.3 in |
| RAID Modes | RAID 0, 1, 10, 5, JBOD |
| OS Compatibility | Windows 7<br />Windows Vista<br />Windows Server 2008<br />Windows Server 2003<br />Windows XP<br />Windows 2000<br />CentOS<br />Linux<br />FreeBSD 7.2 |
| Power Consumption | 10 W |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Operating Humidity | 20 to 80% |
| Storage Temperature | -40 to 140°F / -40 to 60°C |
| Audible Alarm | No |
| Status Monitoring | None |
| Certifications | CE, FCC, as per Manufacturer |
| Mean Time Between Failures (MTBF) | 920.00 Million Hours |
Reviews (1)
1 review for HighPoint RocketRAID 620 6 Gbps SATA RAID Host Adapter
Only logged in customers who have purchased this product may leave a review.
Related products
$554.36
Controller Cards
$153.97
$84.71
Controller Cards
HighPoint SSD7180 PCIe 3.0 x16 8-Channel U.2 NVMe RAID Controller
$419.30
$120.79
Controller Cards
$67.59
Controller Cards
HighPoint SSD7104 PCIe 3.0 x16 4-Channel M.2 NVMe RAID Controller
$319.20
$559.99
Elisha Block
Verified Purchase
I installed it in a data server that doesn’t have a RAID BIOS. It is configured to RAID1 for mirroring with (2) 2TB Western Digital greens. The read/write speed over the network is as good as if it were installed on my PC. The drives show up in the Windows Disk Management and are partitionable. Bench testing showed up to 61.7MB write and 151.7MB read. I looks like when you access to read that it comes from both disks.
