The 4+1-Port CAMSWITCH Mobile Low-Voltage 802.3at PoE Switch from Veracity offers network solution for transport, battery, solar, and low-voltage applications. It is a compact and versatile switch that provides PoE+ from a wide input range of 8.5 to 50VDC. It supplies up to 80 W total power when input is above 10V, 50W when the input voltage drops below 10V. CAMSWITCH Mobile provides a network connection and optional PoE to 4 cameras. PoE is converted to IEEE 802.3af/802.3at levels from a 10 or 40 VDC supply. The power output can be maximized up to 80W of total power, at its rated ambient temperature of 122°F (50°C).
CAMSWITCH Mobile can operate from an 8.5 to 50VDC supply, and step this up to a steady PoE voltage, internally. It is equipped with 4 network ports with 802.3at PoE and one data-only port. All ports support 10/100 Base-T with auto-negotiation and auto-crossover. PoE is delivered on the Ethernet data pairs for compatibility with external 4-pin. The switch has a rugged enclosure with adjustable mounting brackets.
Additional information
| Weight | 0.83 lbs |
|---|---|
| Dimensions | 5.6 × 4.35 × 1.85 in |
| PoE Standard | IEEE 802.3.af/IEEE 802.3at compatible |
| Ports | 4 x Network ports with 802.3at PoE <br> 1 x Data only <br> 1 x 12/24 VDC Power input |
| Rate | 10BASE-T or 100BASE-T and duplex, auto-configuring for speed |
| Cable | Straight through or crossover Cat5, Cat5e, or Cat6 patch |
| Connector | Detachable screw terminal |
| Voltage | 8.5 – 50 V (minimum startup voltage is 10.5 V, supports engine cranking and reduce over-discharge) DC only |
| Fuse Rating | Power Budget: 80 W <br> Fuse Rating (12 V): 10 A<br> Fuse Rating (24 V): 5 A<br><br> Power Budget: 60 W <br> Fuse Rating (12 V): 7.5 A<br> Fuse Rating (24 V): 4 A<br><br> Power Budget: 40 W <br> Fuse Rating (12 V): 5 A<br> Fuse Rating (24 V): 3 A<br><br> Power Budget: 20 W <br> Fuse Rating (12 V): 3 A<br> Fuse Rating (24 V): 2 A<br><br> Power Budget: No PoE <br> Fuse Rating (12 V): 2 A<br> Fuse Rating (24 V): 2 A |
| Power Output | 24 V Input: 80 W total power <br> 12 V Input: 80 W (reduce to 65 W for maximum 86°F (30°C) rise above ambient temperature) <br> |
| LED Indicators | Green: PoE ports Constant: PoE enabled <br> Off: No PoE requested <br> Green: Non-PoE Ports Constant: Power OK <br> Off: No power <br> Yellow<br> Constant: Ethernet OK <br> Blink: Network activity |
| Temperature | 14 to 122°F (-10 to 50°C) |
| Relative Humidity | Up to 85% (non-condensing) |
| Compliance | CE<br> FCC (Part 15)<br> RoHS |
| Mounting Holes | 0.1" (5.0 mm) mounting holes on 4.8" (122.0 mm) centers |
| Dimensions (L x W x H) | Without Clips: 4.3 x 3.9 x 1.5" (110.0 x 100.0 x 40.0 mm) <br> Including Clips: 5.1 x 3.9 x 1.5" (131.0 x 100.0 x 40.0 mm)* |
