Description
Keep crucial systems protected during a power surge with the PST5-500MT120 8-Outlet UPS from Vertiv Liebert. Designed to keep crucial systems running long enough for proper shutdown in the event of a power surge or overage, this UPS features eight surge-protected NEMA 5-15R outlets. Four of the outlets also feature battery backup power. Capable of a total output of 500 VA or 300W, the PST5-500MT120 supports input at 95 to 145VAC at 60 Hz and provides an output of 96 to 145VAC. A circuit breaker with a surge energy rating of 316 Joules protects connected equipment, including network equipment connected via two RJ11/45 ports. This UPS features a typical transfer time of 6 to 8 ms with a maximum of 10 ms and utilizes a sine waveform, ensuring smooth power output.
Utilizing user-replaceable batteries, the PST5-500MT120 features a recharge time of up to 90% in 6 to 8 hours. Connect to a host computer via a USB Type-B port and included cable. The PST5-500MT120 incorporates a 6′ power cable with a NEMA 5-15P plug. A $200,000 Equipment Protection Plan ensures peace of mind in regard to connected equipment.
Additional information
| Weight | 7.53 lbs |
|---|---|
| Dimensions | 15.1 × 9.8 × 6 in |
| Total Outlets | 8 x NEMA 5-15R |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Chemistry | Lead-Acid |
| Full-Load Runtime | 3 Minutes |
| Half-Load Runtime | 9 Minutes |
| User Replaceable | Yes |
| Replacement Battery | CSB GP1221<br />Leoch DJW12-5.0 0 |
| Hot-Swap Support | No |
| Operating Humidity | 0 to 90% |
| Cells | 1 |
| Storage Temperature | 5 to 113°F / -15 to 45°C |
| Operating Altitude | 0 to 4921' / 0.0 to 1499 m |
| Storage Altitude | 0 to 49, 212' / 0.0 to 14, 999 m |
| Noise Level | 40 dBA |
| Certifications | CSA, FCC, cTUVus, as per Manufacturer |
| Cable Length | 5.9' / 1.8 m |
| Rackmount Size | None |
| Battery Capacity | 60 VAh |
| Waveform | Simulated Sine Wave |
| Protected Outlets | 4 x NEMA 5-15R (Battery and Surge)<br />4 x NEMA 5-15R (Surge Only) |
| Transfer Time | 6 to 8 ms |
| Plug Type | NEMA 5-15P |
| USB Charging Ports | None |
| SmartSlot Interface | None |
| Coax Protection | None |
| Data Line Protection | RJ11, RJ45 |
| Communications | USB via Type-B |
| Topology | Standby |
| Surge Energy Rating | 316 Joules |
| Maximum Efficiency | 95% |
| Maximum Wattage | 300 W |
| Nominal Input Voltage | 120 VAC |
| Input Voltage Range | 90 to 145 VAC |
| Input Frequency | 60 Hz (Auto Sensing) |
| Nominal Output Voltage | 120 VAC |
| Output Frequency | 60 Hz ± 0.5% |
| Load Capacity | 500 VA |
| Dimensions (W x H x D) | 12 x 3.82 x 6.24" / 304.8 x 97.03 x 158.5 mm |
Reviews (8)
8 reviews for VERTIV Liebert PST5-500MT120 8-Outlet UPS
Only logged in customers who have purchased this product may leave a review.
Related products
UPS & Accessories
$37.56
UPS & Accessories
$255.83
UPS & Accessories
$85.18
UPS & Accessories
$27.59
UPS & Accessories
$290.95
UPS & Accessories
$324.97
UPS & Accessories
$614.96
UPS & Accessories
$266.96
Rafaela Orn
Verified Purchase
Bought this on sale. I really, really like that the price was quite right at the time I bought this, especially compared to another UPS I bought from a big wholesale chain right before this. Even the non-sale price is right. A modem and WiFi router is plugged to this UPS. The idea was (1) not to be without Internet when the power is out, and (2) protect the modem from surges by passing coax through the UPS. Of these goals, (1) has been met just fine, and (2) has been an abject failure because UPS units (both this one and the other big wholesale store’s one) seem to add interference to the coax connection. There was atrociously bad packet drop rates, and no usable internet when coax went through UPS. Using different cables did not work either, so it probably wasn’t the fault of cables. Maybe coax-through-UPS works for TVs, or maybe a bigger name UPS would work. I don’t know. The Internet says that it is not necessary to add surge protection to properly grounded coax. I don’t know about that either. I guess I will learn more about that eventually, hopefully not the hard way.
Nya Lynch
Verified Purchase
Seems well designed. But Since I use it in a quiet environment where there are brief power hits, the I’m on battery’ beeps are an issue. Even low end APC units allow you to use their app to config notifications. The Vertiv app does not have this feature.
Anya Wisozk
Verified Purchase
Had power at the house flicker on and off. Internet connection remained steady. For the price, I am very, very happy!
Grady Moen
Verified Purchase
Great product for a great price. Works exactly as advertised.
Brandon Jaskolski
Verified Purchase
I bought this to hook up with Synology NAS. Since I tried hooking it up, it is not recognized by Synology DSM… I guess you have utilize their software for PCs. So unfortunately I use it for keeping my network Wi-Fi router and Ethernet switch running… if you want something for your NAS get something else like a APC or Cyberpower.
Arnoldo Davis
Verified Purchase
Not enough power to add a laser copier/printer to back-up, but plenty for a wi-fi unit. True sine-wave output a plus in case you have something small, like a laptop, to back up.
Susana Stark
Verified Purchase
This the perfect UPS appliance for an office with two desktop computers, multiple external hard drives, printers and scanners. There are eight surge protected outlets, four of which are also uninterruptable power supply outlets. There are provisions for coax in and out ports, two cat 5 ports, one standard and one printer USB ports. It’s compact and silent.
Deborah Denesik
Verified Purchase
Works like a charm. A little big, but in this case, I’ll accept that. No issues and setting up was a breeze. No electrical issues at my location since installed and cannot recommend how it would handle in such an event. Overall ; satisfied
