Description
Keep crucial systems protected during a power surge with the PST5-850MT120 8-Outlet UPS from Vertiv Liebert. Designed to keep crucial systems running long enough for proper shutdown in the event of a power surge or overage, this UPS features eight surge-protected NEMA 5-15R outlets. Four of the outlets also feature battery backup power. Capable of a total output of 850 VA or 500W, the PST5-850MT120 supports input at 95 to 145VAC at 60 Hz and provides an output of 96 to 145VAC. A circuit breaker with a surge energy rating of 316 Joules protects connected equipment, including network equipment connected via two RJ11/45 and two coax ports. A USB Type-A charging port is also present, providing 2A of power. This UPS features a typical transfer time of 6 to 8 ms with a maximum of 10 ms and utilizes a sine waveform, ensuring smooth power output.
Utilizing user-replaceable batteries, the PST5-850MT120 features a recharge time of up to 90% in 6 to 8 hours. Connect to a host computer via a USB Type-B port and included cable. Users can also monitor status and performance using the integrated LCD display. The PST5-850MT120 incorporates a 6′ power cable with a NEMA 5-15P plug. A $200,000 Equipment Protection Plan ensures peace of mind in regard to connected equipment.
Additional information
| Weight | 8.74 lbs |
|---|---|
| Dimensions | 15.1 × 9.7 × 6 in |
| Total Outlets | 8 x NEMA 5-15R |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Chemistry | Lead-Acid |
| Full-Load Runtime | 1.5 Minutes |
| Half-Load Runtime | 6 Minutes |
| User Replaceable | Yes |
| Replacement Battery | Leoch DJW12-6.0<br />BB SHR7-12 |
| Hot-Swap Support | No |
| Operating Humidity | 0 to 90% |
| Cells | 1 |
| Storage Temperature | 5 to 113°F / -15 to 45°C |
| Operating Altitude | 0 to 4921' / 0.0 to 1499 m |
| Storage Altitude | 0 to 49, 212' / 0.0 to 14, 999 m |
| Noise Level | 40 dBA |
| Certifications | CSA, FCC, cTUVus, as per Manufacturer |
| Cable Length | 5.9' / 1.8 m |
| Rackmount Size | None |
| Battery Capacity | 72 VAh |
| Waveform | Simulated Sine Wave |
| Protected Outlets | 4 x NEMA 5-15R (Battery and Surge)<br />4 x NEMA 5-15R (Surge Only) |
| Transfer Time | 6 to 8 ms |
| Plug Type | NEMA 5-15P |
| USB Charging Ports | 1 x USB Type-A (2 A) |
| SmartSlot Interface | None |
| Coax Protection | 1-In<br />1-Out |
| Data Line Protection | RJ11, RJ45 |
| Communications | USB via Type-B |
| Topology | Standby |
| Surge Energy Rating | 316 Joules |
| Maximum Efficiency | 95% |
| Maximum Wattage | 500 W |
| Nominal Input Voltage | 120 VAC |
| Input Voltage Range | 90 to 145 VAC |
| Input Frequency | 60 Hz (Auto Sensing) |
| Nominal Output Voltage | 120 VAC |
| Output Frequency | 60 Hz ± 0.5% |
| Load Capacity | 850 VA |
| Dimensions (W x H x D) | 12 x 3.82 x 6.24" / 304.8 x 97.03 x 158.5 mm |
