Description
The MSI Z490-A PRO LGA 1200 ATX Motherboard is built on the Intel Z490 chipset, supporting 10th generation Intel Core and Pentium Gold/Celeron processors with an LGA 1200 socket. It has four memory slots for up to 128GB of dual-channel DDR4 RAM, which can be overclocked to up to 4800 MHz and above. For storage, it’s equipped with six SATA III ports and two M.2 slots. There are two PCIe 3.0 x16 slots for graphics cards and three PCIe 3.0 x1 slots for other PCI-based hardware. Other integrated features include Realtek 8125B 2.5 GbE and Realtek ALC892 7.1-channel HD audio.
Additional information
| Weight | 2.9 lbs |
|---|---|
| Dimensions | 23.6 × 14.8 × 13.4 in |
| Chipset | Intel Z490 |
| RAID Support | RAID 0, 1, 5, 10 (SATA)<br />RAID 0, 1 (M.2) |
| Supported Operating Systems | Windows 10 (64-Bit) |
| Audio Codec | Realtek ALC892 (7.1-Channel) |
| I/O Connection Headers | AAFP, USB 3.1 / USB 3.2 Gen 1 |
| Legacy | 1 x Serial |
| Add-On | 1 x Thunderbolt Card Header |
| Diagnostics | Clear CMOS |
| LED Header | 3 x RGB |
| Security | Chassis Intrusion |
| Power Connectors | 1 x 24-Pin Mainboard<br />1 x 8-Pin CPU<br />1 x 4-Pin ATX |
| Liquid Cooling | 1 x 4-Pin Pump |
| Air Cooling | 1 x 4-Pin CPU<br />6 x 4-Pin System |
| Multi-GPU Support | 2-Way AMD CrossFireX |
| Expansion Slots | 2 x PCIe 3.0 x16<br />3 x PCIe 3.0 x1 |
| Optane Memory Support | Yes |
| CPU Socket | LGA 1200 |
| U.2 | None |
| M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III)<br />1 x M Key 2242, 2260, 2280 (PCIe 3.0 x4, SATA III) |
| SATA | 6 x SATA III |
| ECC Support | Non-ECC, ECC (Non-ECC Mode) Unbuffered |
| Channel Architecture | Dual Channel |
| Maximum Capacity | 128 GB |
| Memory Support | DDR4 2133, 2666, 2933, 4000, 4266, 4400, 4800 MHz |
| Memory Slots | 4 x 288-Pin |
| PS/2 | 1 x PS/2 |
| Ethernet / Controller | 1 x Realtek RTL8125B-CG 2.5Gigabit |
| Display | 1 x HDMI <br />1 x DisplayPort |
| Thunderbolt | None |
| USB | 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 1 USB Type-C Port)<br />2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)<br />2 x USB 2.0 Header (Supports 4 USB Type-A Port) |
| Form Factor | ATX |
Reviews (8)
8 reviews for MSI Z490-A PRO LGA 1200 ATX Motherboard
Only logged in customers who have purchased this product may leave a review.
Related products
Desktop Components
Intel Core i9-9820X X-Series 3.3 GHz Ten-Core LGA 2066 Processor
$423.99
Desktop Components
$466.46
Desktop Components
$84.49
Desktop Components
$201.87
Desktop Components
$12.99
Desktop Components
ASUS Republic of Gamers Ryuo 120 All-in-One Liquid CPU Cooler
$102.75
Desktop Components
$104.64
Desktop Components
$107.99
Heather Upton
Verified Purchase
High end motherboard, came fast and cheap. 10/10 Would buy again
Remington Schuster
Verified Purchase
Can push 2 monitors and has 2 slots for NVMe. Just missing a built in wifi slot. Lots of other port headers and highly reliable. Been using this board for the last 20 builds over the last
Jordy Smith
Verified Purchase
So far my experience has been alright, booted normally, all is well 3 months out from build date. But I had some major issues at time of building with the lack of extra fittings. I mean even the worst quality IKEA furniture comes with at least one extra screw. There were no extra standoff screws, at least for my case. And the worst part is that they included literally zero m.2 securing screws that weren’t captive to their subpar brushed aluminum heatsink. Worst experience I’ve had with an MSI product though, so I cant complain too much as it has worked for me since day one.
Queenie Feeney
Verified Purchase
All i need in
Vidal Denesik
Verified Purchase
Easy to use overclocking and fane curve bios
Preston Carter
Verified Purchase
very simple
Jenifer Klocko
Verified Purchase
Purchased for son’s first build and worked great. Included documentation could be better but the online docs from MSI filled in the gaps. B&H shipping was quick and product arrived well packaged.
Allen Rohan
Verified Purchase
FedEx has misplaced my package but I have five stars of anticipation. I’ve been getting ready for my first build in six years. I became concerned because my new Thermaltake 500W PSU has a 4+4 (8) pin 12V connector but MSI instructions want a 4 pin in addition to an 8 pin. The consensus of forum opinion is: the additional 4 pin connector just supplies additional current for overclocking. This board will probably run fine with only the 8 pin connection but I bought a molex to P4 adapter to put my mind at ease.
